Product description BORA Professional 3.0 Gas-glass ceramic hob PKG3
2-burner gas-glass ceramic hob with high and normal burners
Pot rack removable and dishwasher-safe
Automatic relighting
Keep-warm function
Power level
Residual heat indicator
Pause function
Timer function
Configuration menu
Can be mounted rotated by 180
Cooking zone display on control knob
Demo mode
Automatic boil-on function
Digital power level display on the control knob
Child safety lock
Safety shut-off

Technical data

Supply voltage
230 V
Frequency
50 Hz
Maximum power
5 kW
Connected load maximum
20 W
Fuse protection
1 x 0.5 A
Power levels
1 - 9, P
Weight (incl. accessories / packaging)
11.5 kg
Surface material
SCHOTT CERAN
Mains cable
1,5 m
Dimensions (width x depth x height)
370 x 540 x 73 mm
Power burner front
800 - 3000 W
Normal burner rear
550- 2000 W
Front cooking zone Size
Ø 240 mm
Rear cooking zone Size
Ø 200 mm
Pot rack high burner
270 x 270 x 45 (25) mm
Pot support normal burner
235 x 235 x 45 (25) mm

Scope of delivery:
Gas ceramic hob PKG3
2 x control knobs
Mounting brackets
2 x cast-iron pot supports
Nozzle set G 20/20 mbar natural gas PKGDS2020
Height compensation plate set
Operating and assembly instructions
2 x connecting cable operating toggle
Connecting cable to the fume cupboard
Mains cable 1.5 m (L, N, PE), without plug
Transition piece cylindrical - conical
Seal

Planning information
Provide sufficient ventilation below the gas hob. Either via the carcase front (opening cross-section > 50 cm2 ) or via the plinth area - opening cross-section > 150 cm2.
Provide a return air opening (opening cross-section > 1000 cm2 ) per air purification unit) for the return of recirculated air in the plinth area.
Observe the locally applicable regulations and connection conditions for gas hobs.
Observe the special installation and processing guidelines for the PKG3 gas hob (see operating and installation instructions).
When operating the gas hob with a hob extractor, the gas flame may be affected (depending on the level of the power stage on the hob extractor).
The PKG3 gas hob is SVGW-certified (No. 19-027-1). Observe the locally applicable regulations and connection conditions for gas hobs.
